Branch Crusher

The main function of branch crusher is its mobility and efficient crushing ability. It can quickly convert woody wastes such as branches and trunks into fine particles or fragments for subsequent treatment, utilization or storage.

Main Functions

The main function of branch crusher is its mobility and efficient crushing ability. It can quickly convert woody wastes such as branches and trunks into fine particles or fragments for subsequent treatment, utilization or storage. This equipment is widely used in landscaping, forest maintenance, orchard management, municipal clearing and other fields, effectively solve the problems of wood waste treatment difficulties and high transportation costs.

Scope of Application

The branch crusher is widely used in the following scenarios:

Landscaping: In parks, greenbelts, streets and other green areas, branch crusher can quickly deal with pruned branches and trunks, to maintain the beautiful environment.

Forestry maintenance: In forest, forest farm and other areas, branch crusher can deal with wood waste such as cutting residues and diseased wood, to improve the utilization rate of forestry resources.

Orchard Management: In an orchard, a branch crusher is used to treat the pruned branches and fruit debris, providing a source of organic fertilizer for the orchard.

Municipal cleaning: In urban roads, parks and other public areas, branch crusher can help to clean up tree lodging and leaf accumulation caused by natural disasters (such as typhoons and snowstorms).

Market Prospects

The pellet fuels made by biomass pellet machine have a wide range of applications, mainly including the following aspects:

Civil heating and domestic energy: biomass particulate fuels can be used for domestic heating, hot water supply and other areas of domestic energy, replacing traditional coal and gas and other energy.

Industrial boiler: biomass particulate fuel can be used as the main fuel of industrial boiler, replace traditional energy such as coal, reduce atmospheric emissions and pollution. Biomass power plant: biomass particulate fuel can be used in the power generation process of biomass power plant, to achieve large-scale utilization of biomass energy.

Product Parameters

Model

400

800

1000

Host power

22HP(Diesel engine)/18.5kw

28HP(Diesel engine)/30kw

55kw/4105(Diesel engine)

Cutting insert

2 piece

2 piece

6 piece

Roller crushing blade

12 piece

16 piece

16 piece

Maximum feed diameter

<80mm

<160mm

<250mm

Internal dimensions of the feed inlet

800*400mm

880*450mm

1200*600mm

External dimensions

3200*1300*2200(mm)

3300*1800*2300(mm)

4200*1900*2600(mm)

Production

1-2t/h

2-4t/h

2-6t/h

Operation Process
