Biomass briquetting machine is a kind of machine that compresses different raw materials by using specific working medium (such as mechanical transmission or fluid transmission) to drive pressure. According to its transmission mode and application, the briquetting machine can be divided into several types.
Biomass briquetting machine is a kind of machine that compresses different raw materials by using specific working medium (such as mechanical transmission or fluid transmission) to drive pressure. According to its transmission mode and application, the briquetting machine can be divided into several types. Such as mechanical drive block press (including friction press, press that transmit power through joint, etc.), hydraulic drive block press (such as hydraulic press and hydraulic press), pneumatic drive block press (such as pneumatic press), etc. In addition, according to the different processing materials, there are special metal briquetting machine, straw briquetting machine, straw briquetting machine and so on.
The working principle of the Biomass briquetting machine is mainly based on the pressure principle. In the working process, the material to be treated is first put into the pressure chamber of the briquetting machine, and then the material is compressed into the required shape and specification by exerting great pressure through the pressure column or pressure spoke. This process usually takes several minutes, depending on the characteristics of the material and the type of briquetting machine. The hydraulic system or mechanical drive system provides the required pressure for the press, while the power and control system is responsible for the operation and process control of the whole equipment.
Biomass briquetting machine is widely used in various industrial fields, such as wood processing, bituminous coal production, pharmaceutical, chemical, smelting, construction and so on. In the field of wood processing, Biomass briquetting machine can compress wood chips, straw and other wastes into lumps, which are convenient for storage and transportation, and used as biomass fuel. In the field of bituminous coal production, the Biomass briquetting machine can compress pulverized coal and other raw materials into lump coal to improve the utilization efficiency and combustion effect of coal. In pharmaceutical and chemical industries, the Biomass briquetting machine can compress powdered raw materials into block or flake products, which is convenient for packaging and transportation.
The pellet fuels made by biomass pellet machine have a wide range of applications, mainly including the following aspects:
Civil heating and domestic energy: biomass particulate fuels can be used for domestic heating, hot water supply and other areas of domestic energy, replacing traditional coal and gas and other energy.
Industrial boiler: biomass particulate fuel can be used as the main fuel of industrial boiler, replace traditional energy such as coal, reduce atmospheric emissions and pollution. Biomass power plant: biomass particulate fuel can be used in the power generation process of biomass power plant, to achieve large-scale utilization of biomass energy.
|
Model |
Ostiole |
Power(kw) |
Spindle speed(r/min) |
Capacity(kg/h) |
Quality(kg) |
|
TY75-3 |
36 |
B35Y280S-4 |
138 |
1000-2800 |
5000 |
|
TY75-3 |
36 |
B3Y315S-6 |
144 |
1000-2800 |
4500 |
|
TY90-4 |
72 |
B35Y280M-4 |
138 |
1200-2000 |
5000 |
|
TY90-4 |
72 |
B3Y315M-6 |
144 |
1200-3000 |
5500 |
|
TY45-2 |
24 |
B35280S-6 |
144 |
700-1200 |
3500 |
|
TY37-2 |
24 |
B3Y250M-6 |
144 |
600-1100 |
3000 |
