According to its structure and working principle, Rotary Drier can be divided into a variety of types, such as three-channel dryer, air flow dryer and so on. Among them, the three-channel dryer is the mainstream equipment in the production process of biomass pellets such as wood pellets, which is widely used at home and abroad.
Rotary Drier is generally used in the form of three channels, the drum with a specially designed lifting plate, guide plate and special copy, etc. After the sawdust enters the dryer, the combined material plate and the rotary cylinder act together, the material boils and fluidizes in the cylinder, and the hot air fully contacts with the material to complete the drying process.
Rotary Drier is widely used in wood-based panels, agricultural and animal husbandry engineering, biomass energy and other fields. In particular, it is suitable for that dry of wood shavings, wood chips, river sand, non-metallic mineral powder and other materials, and also suitable for the production of straw, briquette fuel, charcoal machinery, wood chip particle fuel, sawdust briquette and other products.
The pellet fuels made by biomass pellet machine have a wide range of applications, mainly including the following aspects:
Civil heating and domestic energy: biomass particulate fuels can be used for domestic heating, hot water supply and other areas of domestic energy, replacing traditional coal and gas and other energy.
Industrial boiler: biomass particulate fuel can be used as the main fuel of industrial boiler, replace traditional energy such as coal, reduce atmospheric emissions and pollution. Biomass power plant: biomass particulate fuel can be used in the power generation process of biomass power plant, to achieve large-scale utilization of biomass energy.
|
Model |
Diameter(m) |
Capacity(t/h) |
Motor power(kw) |
Volume capacity(m³) |
Evaporation Capacity |
|
φ1.0×12m |
1.0 |
12 |
7.5 |
9.42 |
30-80 |
|
φ1.2×12m |
1.2 |
12 |
7.5 |
13.57 |
|
|
φ1.5×12m |
1.5 |
12 |
7.5 |
21.20 |
|
|
φ1.8×12m |
1.8 |
12 |
11 |
30.52 |
|
|
φ2.0×12m |
2.0 |
12 |
11 |
37.68 |
|
|
φ2.2×12m |
2.2 |
12 |
18.5 |
45.60 |
|
|
φ2.5×24m |
2.5 |
24 |
22 |
117.75 |
|
|
φ2.8×24m |
2.8 |
24 |
37 |
147.71 |
