Comprehensive crusher, also known as comprehensive wood crusher, is a kind of equipment that can break and treat a variety of wood waste. It can deal with waste packing boxes, formwork, plates, branches, wooden boxes, pallets and all kinds of wood with nails or without nails.
Comprehensive crusher, also known as comprehensive wood crusher, is a kind of equipment that can break and treat a variety of wood waste. It can deal with waste packing boxes, formwork, plates, branches, wooden boxes, pallets and all kinds of wood with nails or without nails. Strong impact, shearing and tearing of the wood through a high-speed rotating hammer head or a cutter will break the wood into smaller particles or fragments for easy subsequent treatment or reuse.
The working principle of comprehensive crusher is mainly based on impact force and shear force. When the machine starts, the motor drives the rotor to rotate at a high speed, and the wood is evenly sent into the crushing chamber of the crusher. The high-speed rotating hammer head or cutting tool makes a strong impact on the wood, accompanied by the action of cutting and tearing, so as to break the wood into particles or pieces of the required size.
The pellet fuels made by biomass pellet machine have a wide range of applications, mainly including the following aspects:
Civil heating and domestic energy: biomass particulate fuels can be used for domestic heating, hot water supply and other areas of domestic energy, replacing traditional coal and gas and other energy.
Industrial boiler: biomass particulate fuel can be used as the main fuel of industrial boiler, replace traditional energy such as coal, reduce atmospheric emissions and pollution. Biomass power plant: biomass particulate fuel can be used in the power generation process of biomass power plant, to achieve large-scale utilization of biomass energy.
|
Model |
YC1600-800 |
YC1600-1000 |
YC1800-800 |
YC1800-1000 |
|
Rotor diameter (mm) |
1050 |
1300 |
1050 |
1300 |
|
Number of Flying Knives (Bundle) |
2×3、2×4（Hammer） |
2×3、2×3（Hammer） |
2×3、2×4（Hammer） |
2×3、2×4（Hammer） |
|
Feed opening (mm) |
1600×800 |
1600×1000 |
1800×800 |
1800×1000 |
|
Knife roller speed (rpm) |
650 |
650 |
720 |
720 |
|
Feed speed (m/min) |
Variable frequency automatic speed regulation |
Variable frequency automatic speed regulation |
Variable frequency automatic speed regulation |
Variable frequency automatic speed regulation |
|
Production capacity (m³/h) |
35-50 |
45-60 |
60-100 |
80-160 |
|
Main motor power (kw) |
160-315 |
200-315 |
250-400 |
315-400 |
|
External dimensions (mm) |
9260×2750×2260 |
9270×2920×2390 |
10560×3160×2560 |
10560×3360×2760 |
